F3 675

The superb in-line 675 cc three-cylinder power unit on the new F3 pays homage to the world’s most victorious motorcycle brand. It is with this architecture, in fact, that MV has competed in and won an unprecedented number of races and world championships. Today the 3-cylinder engine is back in a Supersport guise to offer up first-class technical solutions and peak performance.

This compact engine is incredibly short and narrow, an astonishing result achieved by assembling the internal components as only MV knows how. With a 79 mm bore and super-short 45.9 mm stroke, the MV Agusta 3-cylinder engine has an extreme over-square ratio that lets it achieve incredible rev levels. Ultra-advanced, it can put out 128 hp at 14,500 rpm and provide 71 Nm of torque at 10,600 rpm. Thanks also to its 15,000 rpm rev limiter, this performance level - a first in this category - is on a par with that of a number of 4-cylinder engines. And talking of ‘firsts’, this production motorcycle also features a counter-rotating crankshaft, thus honing dynamic balance to perfection and enhancing the lightning-fast handling.

Compact, light and top-of-the-category performance: these are the characteristics that make the new MV Agusta F3 675 engine the dream to chase in the Supersport class, an engine set to become the new supersport benchmark. Major contributions to lightness and compactness have come from closed-deck integration of cylinders in the crankcase, achieved via a single shell-casting, the MVICS platform and the use of titanium for both the intake and exhaust valves.
Another unique feature is integration of the oil and water circuits: the oil/water pump system and all relative flow routing is located inside the engine, ensuring the most powerful Italian 3-cylinder ever also boasts a clean, alluring outline.

The most advanced electronic control system ever seen on a Supersport plays, of course, a key role in the extraordinary performance of this new 3-cylinder bike. A highly sophisticated fuel injection system features two injectors per cylinder, which feed three throttle bodies with a record 50 mm diameter.

The F3 675 also sees the MVICS system make its debut in this category, letting the engine unleash record levels of power and control whatever the riding conditions. All you have to do is select one of the 4 available maps, one of which can be customised to tailor power delivery just the way you like it.

The MVICS system also allows implementation of incredibly advanced 8-level traction control, managed with ease via the dashboard interface.

MV Agusta riders have always known they can count on the very best components and outstanding chassis performance. The new F3 675 is no exception to that rule and offers quality-based excellence that puts plenty of 1000 cc superbikes in the shade.

In true MV tradition the advanced frame features a combination of steel tubing and aluminium side plates; these hug the compact engine tightly, resulting in a Supersport that is streamlined to the max. Packed-in engine dimensions left designers with plenty of scope needed to develop a cutting-edge chassis with a forward pivot point and an exceptionally long single-sided swingarm that ensures exceptional traction and ‘feel’. All without compromising the wheelbase of 1,380 mm - a new record for the category - or the bike weight of just 173 kg.

As you’d expect from an MV, components are of the highest quality. The Marzocchi 43mm front fork is fully adjustable as is the Sachs monoshock with separate nitrogen reservoir. The braking system is the best the market can offer: Nissin radial master cylinder, Brembo radial calipers and 320 mm discs are coupled with ultra-light wheels to reduce unsprung mass even further and so give the F3 675 heaven-sent handling performance.
